3 TECHNICAL DATA
Description of the tool
The tool model P330 has been designed to strap packages with plastic strapping. The plastic strapping is fed
around the package manually or in combination with a strap feeder. The straps are inserted in the tool,
automatically tensioned, sealed by friction welding and separated.
Tool size with battery
Length: 395 mm / 14“
Width: 137 mm / 5“
Height: 143 mm / 5“
Weight: 5,7 kg / 12,57 lbs
Noise information
The A-weighted equivalent continuous sound level at the work place of the machine operator is
typical 84 dB (A). The sound power level is 92 dB (A).
This value was determined according to DIN EN 60745-1 (12.2003).
Deviation K: 2.5 dB
Wear ear protection!
Vibration information
The weighted effective value of the acceleration typically amounts to less than 2.5 m/s
2
.
This value was determined according to DIN EN 60745-1 (12.2003).
Deviation K: 0,6 m/s
2
Strap material
Strap qualities: PET (Polyester) and PP (Polypropylene) plain or embossed.
Use only plastic straps recommended by your sales shop (name and address
on the rear of the operation manual).
Strap dimensions: 19.0 - 25.0 mm / 3/4 - 1" x 0,40 - 1,53 mm / .016 - .060" (see chart of types).
Use only plastic straps with the correct strap dimensions for your tool.
Strap tension
Tensioning force*: Adjustable from 1200 - max. 6000 N / 270 - max. 1350 lbs.
Tensioning speed*: approx. 70 - 87 mm/s / 2,76 - 3,43 inch/sec.
Joint strength*: approx. 75% of the tensile strength of the plastic strap.
* The value depends on the strap quality.
Working temperature
The ambient temperature should be between -10° and 45° C (14° and 113°F).
The best performance is achieved between 15° and 20°C (59° and 68°F).
