8
P330mane.fm
4.3 Wearing plate
In order to protect the P330 when using on packages
with hard and rough surface, the tool can be
equipped with a wearing plate and a disk for level
compensation.
The complete wearing plate together with disk and
fastening screws can be ordered under item number
P33.0121.
If the complete bottom side of the tool has to be
protected, the plate P33.0122 must be used.
4.4 Suspension
When working stationary the P330 can be suspended at a spring loaded balancer by using a suspension
bracket.
For working in normal position a stiff suspension bracket with screws and washers can be ordered under item
number P32.0112.
P33.0122
N1.2221
N1.2221
P32.2031
P33.1305
P32.2069
N1.5124
P33.1306
P33.0121
