3-6
Type 43.0276.01
Type 43.0277.01
43.0276.01 P331/19/1.20-1.53/7.0 P331.0001.01 17.06.14
Item-No. in group Pcs. Description Dimension Field
N1.6504 12 SAFETY WASHER M4 C1+
N44.9140 P33.2113 1 ADHESIVE LABEL D19
[P33.0212] 1 BASE MODEL D6+
P33.1259 2 GUIDE PIN D12
[P33.2113] P33.0212 1 MOTOR HOUSING B19
[P33.2116] P33.0212 1 CIRCUIT BOARD 36V B21
P33.2118 P33.0212 1 TOUCH CONTACT-SWITCH A21
P33.2141 1 STRAP GUIDE D4
P33.2229 * 1 TENSIONING WHEEL C4
P35.4103 1 STEEL INSERT D9
P35.4185 * 1 GRIPPER D3
P35.4186 * 1 GRIPPER D3
P35.4187 * 1 GRIPPER D3
P35.4194 1 STRAP STOP B1
P35.4202 1 GUIDE CASE C12
43.0277.01 P331/19/1.20-1.53/7.0/A P331.0002.01 17.06.14
Item-No. in group Pcs. Description Dimension Field
N1.6504 12 SAFETY WASHER M4 C1+
N44.9169 P33.2151 1 ADHESIVE LABEL D19
N5.2382 P33.2120 1 MICRO SWITCH C23
[P33.0213] 1 BASE MODEL D6+
P33.1259 2 GUIDE PIN D12
[P33.2120] P33.0213 1 SWITCH A21
[P33.2138] P33.0213 1 CIRCUIT BOARD 36V B21
P33.2141 1 STRAP GUIDE D4
[P33.2151] P33.0213 1 MOTOR HOUSING B19
P33.2229 * 1 TENSIONING WHEEL C4
P35.4103 1 STEEL INSERT D9
P35.4185 * 1 GRIPPER D3
P35.4186 * 1 GRIPPER D3
P35.4187 * 1 GRIPPER D3
P35.4194 1 STRAP STOP B1
P35.4202 1 GUIDE CASE C12
