[ ] = Group * = Wearing parts
3-7
Type 43.0282.01
Type 43.0283.01
43.0282.01 P331/25/0.60-0.79/7.0 P331.0001.01 17.06.14
Item-No. in group Pcs. Description Dimension Field
N1.6504 10 SAFETY WASHER M4 C1+
N44.9140 P33.2113 1 ADHESIVE LABEL D19
[P33.0212] 1 BASE MODEL D6+
P33.1236 1 GUIDE PIN D12
P33.1237 1 GUIDE PIN D12
[P33.2113] P33.0212 1 MOTOR HOUSING B19
[P33.2116] P33.0212 1 CIRCUIT BOARD 36V B21
P33.2118 P33.0212 1 TOUCH CONTACT-SWITCH A21
P33.2139 1 STEEL INSERT D9
P33.2149 1 STRAP GUIDE D4
P33.2230 * 1 TENSIONING WHEEL C4
P35.4188 * 1 GRIPPER D3
P35.4189 * 1 GRIPPER D3
P35.4190 * 1 GRIPPER D3
P35.4193 1 STRAP STOP B1
P35.4202 1 GUIDE CASE C12
43.0283.01 P331/25/0.60-0.79/7.0/A P331.0002.01 17.06.14
Item-No. in group Pcs. Description Dimension Field
N1.6504 10 SAFETY WASHER M4 C1+
N44.9169 P33.2151 1 ADHESIVE LABEL D19
N5.2382 P33.2120 1 MICRO SWITCH C23
[P33.0213] 1 BASE MODEL D6+
P33.1236 1 GUIDE PIN D12
P33.1237 1 GUIDE PIN D12
[P33.2120] P33.0213 1 SWITCH A21
[P33.2138] P33.0213 1 CIRCUIT BOARD 36V B21
P33.2139 1 STEEL INSERT D9
P33.2149 1 STRAP GUIDE D4
[P33.2151] P33.0213 1 MOTOR HOUSING B19
P33.2230 * 1 TENSIONING WHEEL C4
P35.4188 * 1 GRIPPER D3
P35.4189 * 1 GRIPPER D3
P35.4190 * 1 GRIPPER D3
P35.4193 1 STRAP STOP B1
P35.4202 1 GUIDE CASE C12
