Fromm P331 M - Page 8

1-13
Pay attention to the position of the joint from the slide bearings N31.3111 and N3.3189. (see drawing)
Pay attention to the position of the joint from the slide bearings N3.3166 and N3.3103. (see drawing)
2
0
,
4
5
+
-
0
,
2
P33.2102
(4,5)
press in pin flush
N31.3111
N3.3189
position joint
position joint
P33.2103
press in measure
bolt P33.2103 into
body P33.2102
N3.3166
position joint
position joint
N3.3103
P33.2109
P35.4197
3 X N21.2106
N2.2119
3
6
press in measure
parallel pin N2.2119
into end cover P35.4197
1
2
press in measure of the
parallel pins N21.2106
into gear body P33.2109
