6
Inserting the lower strap
The lifting handle is raised with the right hand. The
lower strap is inserted into the seal and the stop
behind the gripper respectively. The strap end should
slightly protrude the seal.
By lowering the lifting handle the strap is clamped in
its position.
Inserting the upper strap
The tool is held with the right hand. The left hand
inserts the upper strap into the seal, through both
cutters and into the tensioning drum.
Notice: the strap may be inserted into the tool in the
best possible way if the tensioning drum has been
brought into the position shown.
Tensioning of the plastic strap
By operating the tension handle, the strap is
tensioned to the desired amount of tension.
Sealing the strapping
The seal is closed by a forward movement to the
stop of the sealing lever.
