Fronius MTG 270i - Page 36

Fit the contact tip and gas nozzle; mark the inner liner at the end of the PowerPin
4
Cut and deburr the inner liner at the previously marked position; make sure that no burr protrudes into the inner
liner
5
6 7
**** Screw the cap onto the inner liner up to the stop. The inner liner needs to be visi-
ble through the hole in the cap.
36
