Warning notices
inside the device
Inside of device:
Software update The battery charging system can be updated using a USB stick. Detailed instructions for
the update process can be found in the relevant operating instructions.
Technical data Please refer to the operating instructions for the technical data of the device variants.
The charger can cause DC fault currents in the ground conductor. If a fault cur-
rent protection device (RCD) is used on the mains side to protect against electric
shock, it must conform to Type B.
Do not dispose of used chargers with domestic waste. Dispose of them accord-
ing to safety rules.
WARNING! An electric shock can be fatal. The housing may only be opened by
a service engineer who has been trained by the manufacturer. The device must
be disconnected from the mains before starting any work with the housing
opened. A suitable measuring instrument must be used to ensure that electrically-
charged components (e.g. capacitors) are fully discharged. Use an easily legible
and understandable warning sign to ensure that the device is not reconnected to
the mains supply before all the work has been completed.
(4)
(5)
(+)
(-)
(1)
(2)
(3)
RCS 3.0 Lights
1
2
3
4
12V
GREEN
YELLOW
RED
BLUE
+/-
Temp. Sensor
Ext. Start/Stop
WARNING
Hazardous Voltage
Kondensator Entladezeit < 2 min.
Capacitor discharge time < 2 min.
Décharge de condensateur < 2 min.
Risk of Electric Shock!
Do not operate at circuits
more than 250 V to ground!
0... 30V DC/4A
0... 250V AC/4A
Use Copper Conductors Only!
C Common
NC Normally Closed
NO Normally Opened
L Line
N Neutral Wire
max. 1A
AC Output!
42,0409,0008
C NC NO C NC NO C NC NO
L/C NC NO N
WARNING!
To Next Page
