Fronius Selectiva 4120 - Status LED Display

92
Status LED dis-
play
LED LED status Status of the device
Red LED on steady Device is showing a fault - intermittent charging. State code
is shown on the display
pulsates
briefly every
3 secs.
Device is showing a warning - charging is continuous. State
code and state of charge alternate on the display
Orange LED on steady Device is charging
flashes every
second
Intermittent charging caused by Start/Stop button, external
start/stop, calendar function, temperature sensor and
charging start delay
Green LED on steady Charging ended
flashes every
second
Charging ended Water refill indicator has tripped
Blue LED on steady - Set battery cool-down time was reached after charge
end. Green LED also on
- Set battery cool-down temperature was reached after
charge end. Green LED also on
flashes every
second
- Set battery cool-down time was reached after charge
end and water refill indicator has tripped. Green LED
also on
- Set battery cool-down temperature was reached after
charge end and water refill indicator has tripped. Green
LED also on
