Fronius Smart Meter TS 65A-3 - Configuring the Fronius Smart Meter TS as the Primary Meter; Configuring the Fronius Smart Meter TS as a Secondary Meter

Technical data
Technical data Modbus transmission speed: 9600 baud
Parity bit:none
Software version:
- Fronius Datamanager 2.0 (from version 3.16.1 onwards)
- Fronius Symo Hybrid (from version 1.16.1 onwards)
Measuring input
Nominal voltage (4-conductor)
Operating range
208 - 400 V
167 - 480 V (± 20%)
Power consumption in the voltage path
(max. voltage)
≤ 10 VA
Nominal frequency
Tolerance
50 - 60 Hz
45 - 65 Hz
Nominal current, l
b
5 A
Maximum current, I
max
65 A
Starting current 20 mA
Short-time overload
(EN IEC 62053-21, EN IEC 62053-23)
30 l
max
/ 0.001 s
Self-consumption - current path (max. cur-
rent)
≤ 1 W
Power factor
Operating range
(EN IEC 62053-21, EN IEC 62053-23)
active cosφ 0.5 ind - 0.8 cap,
reactive sinφ 0.5 ind - 0.5 cap
Current distortion factor in acc. with EN 50470
Data output
RS485 communication
Electrically isolated from measuring input
Standard RS485 - 3 conductors
Transmission Serial, asynchronous
Protocol Compatible with Modbus RTU
Addresses 1 - 255
Number of bits 8
Stop bit 1
Parity bit None - odd - even
Baud rate 300, 2400, 9600 bit/s
Response time ≤ 200 ms
Insulation (EN IEC 62052-11, EN IEC 62053-21)
Installation category III
Degree of pollution 2
34
