15
EN-US
Knock or drill out
knockouts
IMPORTANT! The knockouts on the underside of the wall bracket may be knocked out us-
ing a hammer or screwdriver, drilled out using a step drill or opened using a hole punch.
The side knockouts and the knockouts at the back may only be drilled out with a step drill
or opened with a hole punch.
Use suitable eye protection when knocking/drilling out the knockouts.
Only knock out knockouts using a hammer or screwdriver from the in-
side outwards.
Only use suitable step drills to drill out the knockouts.
Do not use spiral drills for drilling out!
Only drill out knockouts using a step drill from the outside inwards.
When drilling out using a step drill, ensure that the DC disconnector
and the AC/DC connection block are not damaged.
When drilling out the knockouts at the back, place the wall bracket on
an even surface with the back upwards so that shavings and pieces
of metal can fall out of the wall bracket.
Attach appropriate conduits to all knocked/drilled out knockouts.
In the event of installation outside, only use watertight conduits and
conduit fittings.
Conduits and conduit fittings are not included with the inverter.
*
