Setup MG5N Setup MG6
V
AC
[V] Clearing Time [s]
Clearing Time [p]
V
AC
[V] Clearing Time [s]
Clearing Time [p]
V outer limit min 133 0.56
28
133 0.5
28
V inner limit min 212 0.56
28
212 0.5
28
V outer limit max 318 0.56
28
318 0.5
28
V inner limit max 318 0.56
28
318 0.5
28
V outer limit MIN
adjustable
120–252 0.016–21.0
1–1050
120–275 0.016–21.0
1–1260
V outer limit MAX
adjustable
251–332 0.016–21.0
1–1050
279–332 0.016–21.0
1–1260
V-VDPR 305 V -9%/V 132 V -9%/V
Frequency 60 Hz (for all MG setups) Frequency 50 Hz (for all MG setups)
F [Hz] Clearing Time [s]
Clearing Time [p]
F [Hz] Clearing Time [s]
Clearing Time [p]
F
Imax
+ 2.8 > 62.8 0.5
28
F
Imax
+ 2.8
> 52.8 0.56
28
F
Omax
+ 2.8 > 62.8 0.5
28
F
Omax
+ 2.8
> 52.8 0.56
28
F
Imin
- 4.0 < 56.0 0.5
28
F
Imin
- 4.0
< 46.0 0.56
28
F
Omin
- 4.0 < 56.0 0.5
28
F
Omin
- 4.0
< 46.0 0.56
28
F
Imin
adjustable
F
Omin
adjustable
55.0 -
65.0
0.016–600
1–36,000
45.0 -
55.0
0.020–600
1–30,000
F
Imax
adjustable
F
Omax
55.0 -
65.0
0.016–600
1–36,000
45.0 -
55.0
0.020–600
1–30,000
f-FDPR 61 Hz -60%/Hz 51 Hz -60%/Hz
