Fronius Symo 12.0-3 208-240 - Page 42

42
V outer limit max 264 1
50
305 1
58
V inner limit max 288 0.16
8
332 0.16
9
V outer limit MIN
adjustable
120–252 0.016–21.0
1–1050
120–275 0.016–21.0
1–1260
V outer limit MAX
adjustable
251–332 0.016–21.0
1–1050
127–332 0.016–21.0
1–1260
Setup 50HN Setup HI3
V
AC
[V] Clearing Time [s]
Clearing Time [p]
V
AC
[V] Clearing Time [s]
Clearing Time [p]
Frequency 60 Hz (for all setups) Frequency 50 Hz (for all setups)
F [Hz] Clearing Time [s]
Clearing Time [p]
F [Hz] Clearing Time [s]
Clearing Time [p]
F
Imax
+ 0.5 > 60.5 0.16
9
F
Imax
+ 0.5
> 50.5 0.16
8
F
Omax
+ 2.0 > 62.0 0.16
9
F
Omax
+ 2.0
> 55.0 0.16
8
F
Imin
- 0.7 < 59.3 0.16
9
F
Imin
- 2.0
< 48.0 0.16
8
F
Omin
- 3.0 < 57.0 0.16
9
F
Omin
- 5.0
< 45.0 0.16
8
F
Imin
adjustable
F
Omin
adjustable
55.0 -
65.0
0.016–600
1–36,000
45.0 -
55.0
0.020–600
1–30,000
F
Imax
adjustable
F
Omax
55.0 -
65.0
0.016–600
1–36,000
45.0 -
55.0
0.020–600
1–30,000
Accuracy 60 Hz 50 Hz
Voltage trip limit accuracy +/- 1.0% of U
nom
+/- 1.0% of U
nom
Frequency trip limit accuracy +/- 0.05 Hz +/- 0.05 Hz
Trip time accuracy +/- 16.7 ms (1 cycle) +/- 20 ms (1 cycle)
Detection time 25 ms (1.5 cycles) 30 ms (1.5 cycles)
Reconnection 60 Hz 50 Hz
Reconnection time 20 s 20 s
Reconnection time adjustable 5–900 s 5–900 s
F
max
reconnect value 60.5 Hz 50.5 Hz
F
min
reconnect value 59.3 Hz 48 Hz
U
min
reconnect value U > 88% U > 88%
U
max
reconnect value U < 106% U < 106%
F reconnect value adjustable 55.0–65.0 Hz 45.0–55.0 Hz
U
min
reconnect value adjustable U > 50%–U > 99% U > 50%–U > 99%
U
max
reconnect value adjustable U < 101%–U < 120% U < 101%–U < 120%
