Fronius Symo GEN24 6.0 User Manual

Permissible humidity 0–100% (incl. condensation)
EMC emission class B
DC/AC overvoltage category
(in accordance with IEC 62109-1)
2 / 3
Pollution degree 2
Sound pressure 47 dB(A)
Safety class (according to IEC62103) 1
Protection devices
DC isolation measurement Warning / shutdown at R
ISO
< 100
kOHM
Overload performance Operating point shift, power limiter
DC disconnector Integrated
RCMU Integrated
Active anti-islanding method Frequency conversion method
Data communication
WLAN SMA-RP connection
(FCC ID: QKWPILOT01 / IC ID:
12270A-PILOT01)
802.11b/g/n (WPA, WPA2)
Ethernet (LAN) RJ 45, 10/100 MBit
Wired shutdown (WSD) max. 28 devices/WSD chain
max. distance between two devices =
100 m
Modbus RTU SunSpec (2x) RS485 2-wire
Voltage level of digital inputs
low: min. 0 V–max. 1.8 V
high: min. 4.5 V–max. 28.8 V
Input currents of digital inputs depending on the input voltage;
input resistance = 70 kOhm
Total power for digital output (for in-
ternal supply)
6 W at 12 V (USB not connected)
Power per digital output
(for external supply)
1 A at >12.5 V-24 V
(max. 3 A in total)
Datalogger/web server Integrated
Fronius Symo
GEN24 10.0 /
10.0 Plus
DC input data
MPP voltage range
(at rated power)
278 - 800 V
Max. connected load (P
PV max
)
Total
PV 1
PV 2
15000 Wp
12500 Wp
7500 Wp
166

Fronius Symo GEN24 6.0 Specifications

General

AC nominal output	6.0 kW
Protection class	IP66
Topology	Transformerless
Operating temperature range	-25°C to +60°C
AC nominal voltage	230 V
Number of MPP trackers	2
Maximum Input Voltage	1000 V
Cooling	Active cooling
Max. apparent AC power	6000 VA
AC voltage range	160 V - 280 V
Max. input current (DC)	12.5 A
MPP voltage range	80 V - 800 V
Max. DC power	9000 W
Maximum Input Power	9000 W
MPPT Range	80 V - 800 V
Warranty	5 years
