Fronius Symo User Manual

9
EN
General com-
ments regarding
inverter installa-
tion location
The following criteria should be taken into account when choosing a location for the invert-
er:
Do not install the inverter on a vertical wall or pillar with its connection
sockets facing upwards.
Do not install the inverter such that it overhangs with its connection sock-
ets facing upwards.
Do not install the inverter such that it overhangs with its connection sock-
ets facing downwards.
Do not install the inverter on the ceiling.
Install only on a solid, non-flammable surface
Max. ambient temperatures:
-25 °C / +60 °C
Relative humidity:
0 - 100%
The airflow within the inverter is from the
left to the top (cold air taken in from the
left, hot air dissipated out of the top).
The exhaust air can reach a temperature
of 70 °C.
If the inverter is installed in a switch cabinet or a similar sealed area, then forced-air ven-
tilation must be provided to ensure adequate heat dissipation.
If the inverter is to be installed on the outer wall of a cattle shed, maintain a minimum all-
round clearance of 2 m between the inverter and all ventilation and other openings in the
building.
The installation location must not be exposed to ammonia, corrosive vapours, salts or ac-
ids.
100 mm
100 mm
150 mm
-25 °C - +60 °C
0 - 100 %

Fronius Symo Specifications

General

THD	< 3 %
Number of MPP Trackers	2
Protection Class	IP65
Frequency Range	50 / 60 Hz
Operating Temperature Range	-25°C to +60°C
Power Range	3.0 kW - 20.0 kW
AC Output Voltage	230 V
Communication	Ethernet
Warranty	5 years
Model	Symo
