Yard control panel
Yard control pan-
el
No. Function
(1) Inch Forward (feeder inching) button
for feeding the wire electrode into the torch-hosepack with no accompanying flow
of gas or current
For information on the various wire feed sequences that are possible when the
welder presses and holds the "Feeder inching" button, see the Fdi parameter in
the Setup menu.
