2.7 Installing the JIB Cradle
Open the fryer door (typically the far right door)
and remove the cross brace used for shipping
support by removing the four screws (see Figure
1). Install the JIB cradle shipped in the accesso-
ries pack with the screws that were removed in
the cross brace removal step (see Figure 2). If
using the solid shortening option see Appendix A
in the rear of this manual for installation instruc-
tions. Install the optional JIB splash shield to
protect the bottom of the JIB (see Figure 3).
Figure 1 Figure 2
Figure 3
