MAINTENANCE
37
ALWAYS WEAR PROTECTIVE EYEWEAR AND GLOVES WHEN PERFORMING ANY MAINTENANCE.
MAINTENANCE OF THE SLUG PRO GUN SHOULD BE PERFORMED ON ONLY ONE SIDE (A-SIDE
or B-SIDE) AT A TIME. FOR EXAMPLE, PERFORM MAINTENANCE ON THE A-SIDE ONLY AND PUT
BACK TOGETHER BEFORE WORKING ON THE B-SIDE.
The most important part of maintenance is keeping the equipment clean. Care should be taken to prevent
foam or the individual A-SIDE and B-SIDE from hardening on the Gun Body, Flow Controllers, Ball Valves,
etc. Overall cleanliness of the SLUG PRO gun will reduce excessive maintenance, replacement of parts,
and costs.
MIX TUBES
Mix tubes should be replaced and/or cleaned on a regular basis. It is highly dependent on the usage as to
the life of the mix tube.
MIX TUBE CHANGE OUT PROCEDURE
1. Unscrew and remove Mix Tube Collar.
2. Remove used Mix Tube and set aside for cleaning or throw away.
3. Clean and lubricate insert threads.
4. Replace Mix Tube Collar. Again, hand tight is sufficient.
MIX TUBE CLEANING PROCEDURE
1. Mix Tubes should be set aside until foam hardens.
2. Use 12"L x 3/8" diameter carriage bolt to knock the Mix Element out the bell (closest to block) end of
the Mix Tube.
3. Remove foam from Mix Element.
4. Clean and remove remaining foam from mix tube.
5. Replace cleaned Mix Element into the bell end of the Mix Tube as far as possible.
Note: It is best to store SLUG PRO gun facing down.
MIX TUBE COLLAR
(SL82)
MIX ELEMENT
Bell End of Mix Tube
MIX TUBE
