Parameters:
ftHandle
Handle of the device.
spiMode
SPI mode could be:
 SPI_IO_SINGLE
 SPI_IO_DUAL
 SPI_IO_QUAD
Return Value:
FT4222_OK if successful, otherwise the return value is an FT error code.
Error code:
FT4222_DEVICE_NOT_OPENED: The initialization API is not called.
FT4222_IS_NOT_SPI_MODE: Device does not be configured to SPI Master mode.
FT4222_NOT_SUPPORTED: SPI Master only support single/dual/quad mode, others are not allowed.
Prerequisite:
FT4222_SPIMaster_init
3.3.3 SPI Master Single Read
FT4222_STATUS FT4222_SPIMaster_SingleRead(FT_HANDLE ftHandle, uint8* buffer, uint16
bytesToRead, uint16* sizeOfRead, BOOL isEndTransaction)
Supported Chip:
FT4222 chip version
Supported
FT4222 Rev A
YES
FT4222 Rev B
YES
FT4222 Rev C
YES
FT4222 Rev D
YES
Summary:
Under SPI single mode, read data from an SPI slave.
Parameters:
ftHandle
Handle of the device.
Buffer
Pointer to the buffer that receives the data from the device.
bytesToRead
Number of bytes to read from the device.
sizeOfRead
Pointer to a variable of type uint16 which receives the number of bytes read
from the device.
isEndTransaction
If TRUE the Slave Select pin will be raised at the end of the read.
Return Value:
FT4222_OK if successful, otherwise the return value is an FT error code.
Error code:
FT4222_DEVICE_NOT_OPENED: The initialization API is not called.
FT4222_INVALID_POINTER: Pointer is a NULL pointer.
FT4222_IS_NOT_SPI_SINGLE_MODE: Device is not in SPI Master Single mode
FT4222_FAILED_TO_WRITE_DEVICE: Write data timeout or failed. FT_SetTimeouts can be called
to extend timeout.
FT4222_FAILED_TO_READ_DEVICE: Failed to read data.
