Return Value:
FT4222_OK if successful, otherwise the return value is an FT error code.
Error code:
FT4222_DEVICE_NOT_SUPPORTED: This device is not a FT4222 chip.
FT4222_I2C_NOT_SUPPORTED_IN_THIS_MODE:I2C is not supported in mode 1 and mode 2.
Example:
FT_HANDLE ftHandle = NULL;
FT_STATUS ftStatus;
FT4222_STATUS ft4222Status;
ftStatus = FT_Open(0, &ftHandle);
if (FT_OK != ftStatus)
{
// open failed
return;
}
// initial i2c master with 1000K bps
ft4222Status = FT4222_I2CMaster_Init(ftHandle, 1000);
if (FT4222_OK != ft4222Status)
{
// i2c master init failed
return;
}
FT4222_UnInitialize(ftHandle);
FT_Close(ftHandle);
3.6.2 I
2
C Master Read
FT4222_STATUS FT4222_I2CMaster_Read(FT_HANDLE ftHandle, uint16 slaveAddress, uint8*
buffer, uint16 bytesToRead, uint16* sizeTransferred)
Supported Chip:
FT4222 chip version
Supported
FT4222 Rev A
YES
FT4222 Rev B
YES
FT4222 Rev C
YES
FT4222 Rev D
YES
Summary:
Read data from the specified I2C slave device with START and STOP conditions.
Parameters:
ftHandle
Handle of the device.
slaveAddress
Address of the target I
2
C slave.
buffer
Pointer to the buffer that receives data from the device.
bytesToRead
Number of bytes to read from the device.
sizeTransferred
Pointer to a variable of type uint16 which receives the number of bytes read
from the device.
Return Value:
FT4222_OK if successful, otherwise the return value is an FT error code.
