SR = repeated START condition
Here is an example for typical usage of I
2
C combined message:
// Write to I2C slave with START bit
FT4222_I2CMaster_WriteEx(ftHandle, deviceAddress, START, buffer, bufferSize,
sizeTransferred);
// Read from I2C slave with Repeated START and STOP bit
// Use Repeated_START flag instead of START to avoid the FT4222H sending master
code
// again in HS mode
FT4222_I2CMaster_ReadEx(ftHandle, deviceAddress, Repeated_START | STOP, buffer,
bufferSize, sizeTransferred);
3.6.6 I
2
C Master GetStatus
FT4222_STATUS FT4222_I2CMaster_GetStatus(FT_HANDLE ftHandle, uint8 *controllerStatus)
Supported Chip:
FT4222 chip version
Supported
FT4222 Rev A
YES
FT4222 Rev B
YES
FT4222 Rev C
YES
FT4222 Rev D
YES
Summary:
Read the status of the I
2
C master controller. This can be used to poll a slave after i2c
transmission is complete.
Parameters:
ftHandle
Handle of the device.
controllerStatus
Address of byte to receive status flags:
bit 0: controller busy: all other status bits invalid
bit 1: error condition
bit 2: slave address was not acknowledged during last operation
bit 3: data not acknowledged during last operation
bit 4: arbitration lost during last operation
bit 5: controller idle
bit 6: bus busy
The header file provides convenience macros (such as I2CM_BUS_BUSY) to
test these bits.
Return Value:
FT4222_OK if successful, otherwise the return value is an FT error code.
Prerequisite:
FT4222_I2CMaster_Init
