Supported Chip:
FT4222 chip version
Supported
FT4222 Rev A
YES
FT4222 Rev B
YES
FT4222 Rev C
YES
FT4222 Rev D
YES
Summary:
Initialize the FT4222H as an SPI slave. Default SPI_SlaveProtocol is
SPI_SLAVE_WITH_PROTOCOL. The default setting may be replaced with another SPI SLAVE
initialization API FT4222_SPISlave_Init_EX.
Parameters:
ftHandle
Handle of the device.
Return Value:
FT4222_OK if successful, otherwise the return value is an FT error code.
Error code:
FT4222_DEVICE_NOT_SUPPORTED: This device is not a FT4222 chip.
3.4.2 SPI Slave Init extend function
FT4222_STATUS FT4222_SPISlave_InitEx(FT_HANDLE ftHandle , SPI_SlaveProtocol
protocolOpt)
Supported Chip:
FT4222 chip version
Supported
FT4222 Rev A
YES
FT4222 Rev B
YES
FT4222 Rev C
YES
FT4222 Rev D
YES
Summary:
Initialize the FT4222H as an SPI slave. It is similar to FT4222_SPISlave_Init with parameters to
define the SPI Slave Protocol.
Parameters:
ftHandle
Handle of the device.
protocolOpt
SPI SLAVE protocol could be:
 SPI_SLAVE_WITH_PROTOCOL
With the full SPI SLAVE PROTOCOL supported. Refer to chapter 3.4
 SPI_SLAVE_NO_PROTOCOL
Remove SPI SLAVE protocol, users can design their own protocol.
 SPI_SLAVE_NO_ACK
Retain SPI SLAVE protocol but remove command ‘ACK’
Return Value:
FT4222_OK if successful, otherwise the return value is an FT error code
