9-21
(2) Functions for standard frame (monitor data)
Table 9-4-6 Standard frame (monitor data)
Name Command
type
character
Function type
character and
number
Data and operation
Frequency
(Final value)
R M01
±20000d/fmax (Max. frequency)
Frequency
command value
R M05
100=1.00Hz (Value multiplied by 100)
The current frequency setting is returned.
Calculated torque
value
R M07
100% (rated torque) / ± 10000 (value multiplied
by 100)
Torque current R M08
100% (rated current) / ± 10000
(value multiplied by 100)
Output frequency R M09
100=1.00Hz
(Value multiplied by 100; special additional
data: sign)
The current output frequency is returned.
Motor output
(power
consumption)
R M10
100% (rated output) / ± 10000
(value multiplied by 100)
Output current R M11
100 = 1% of rated inverter current
The current output current is returned in the
ratio to the rated current.
Output voltage R M12 10=1V
Operation command
R M13
bit15:RESET 1:ON,0:OFF
bits 14 to 5: Fixed to 0
bit6:X5 1:ON, 0:OFF
bit5:X4 1:ON, 0:OFF
bit4:X3 1:ON, 0:OFF
bit3:X2 1:ON, 0:OFF
bit2:X1 1:ON, 0:OFF
bit 1: REV (reverse rotation command)
1:ON,0:OFF
bit 0: FWD (forward rotation command)
1:ON,0:OFF
The final command value including the state of
the actual control terminal of the inverter is
returned.
Operation status R M14
bit 15: Function code data being written
bit 12: 1: Communication valid
bit 11: 1: Batch failure (tripping)
bit 10: 1: During deceleration
bit 9: 1: During acceleration
bit 8: 1: Current limit operation
bit 7: 1: Voltage limit operation
bit 6: 1: Torque limit operation
bit 5: 1: DC link voltage established
bit 4: 1: During braking
bit 3: 1: During output shutoff
bit 2: 1: During DC braking
bit 1: 1: During reverse rotation
bit 0: 1: During forward rotation
General purpose
output terminal
R M15
bit 1: Y2; active upon "1"
bit 0: Y1; active upon "1"
