Fuji Electric FVR-E11S-7EN

5-4
E: Extension terminal functions
Function
code
Name Setting range
Min.
unit
Factory
setting
Change during
operation
RS485
Data
format
User
setting
E01 X1 terminal function 0 X 0
E02 X2 terminal function 1 X 0
E03 X3 terminal function 2 X 0
E04 X4 terminal function 6 X 0
E05 X5 terminal function
0: Multistep frequency selection [SS1]
1: Multistep frequency selection [SS2]
2: Multistep frequency selection [SS4]
3: Multistep frequency selection [SS8]
4: Acceleration/deceleration time selection
[RT1]
5: 3-wire operation stop command [HLD]
6: Coast-to-stop command [BX]
7: Alarm reset [RST]
8: Trip command(External fault) [THR]
9: Frequency setting 2/1 [Hz2/Hz1]
10: Motor 2/ Motor 1 [M2/M1]
11: DC brake command [DCBRK]
12: Torque limiter 2/Torque limiter 1 [TL2/TL1]
13: UP command [UP]
14: DOWN command [DOWN]
15: Write enable for KEYPAD [WE-KP]
16: PID control cancel [Hz/PID]
17: Inverse mode changeover [IVS]
(terminal 12 and C1)
18: Link enable [LE]
1
7 X 0
E10 Acceleration time 2 10.0 6
E11 Deceleration time 2
0.01 to 3600s 0.01s
10.0 6
E16
Torque limiter 2
(Driving)）
20 to 200%
999: Inactive
1% 180 0
E17 (Brake)
0%: Automatic deceleration control,
20 to 200%
999: Inactive
1% 150 0
E20 Y1 terminal function 0 X 0
E21 Y2 terminal function
0: Inverter running [RUN]
1: Frequency equivalence [FAR]
2: Frequency level detection [FDT]
3: Undervoltage detection signal [LV]
4: Torque polarity [B/D]
5: Torque limiting [TL]
6: Auto restarting [IPF]
7: Overload early warning [OL]
8: Life time alarm [LIFE]
9: Frequency level detection 2 [FAR2]
1
7 X 0
E29
Frequency level
detection delay
0.01 to 10.0s 0.01s 0.1 6
E30
FAR function signal
(Hysteresis)
0.0 to 10.0Hz 0.1Hz 2.5 2
E31
FDT function signal
(Level)
0 to 400Hz 1Hz 50 0
E32 (Hysteresis) 0.0 to 30.0Hz 0.1Hz 1.0 2
E33
OL function signal
(Mode select)
0: Electronic thermal overload relay
1: Output current
1 0 0
E34 (Level) 20 to 200% of the rated inverter current 0.01A
Fuji’s rated
motor
current
6
E35 (Timer ) 0.0 to 60.0s 0.1s 10.0 2
E40
Display coefficient
A
0.00 to 200.0 0.01 0.01 6
E41 B 0.00 to 200.0 0.01 0.00 6
E42 LED display filter 0.0 to 5.0s 0.1s 0.5 2
