(E:Extension Terminal Functions)
E01 X1 terminal function
E02 X2 terminal function
E03 X3 terminal function
E04 X4 terminal function
E05 X5 terminal function
The function of each digital input terminal X1 to
X5 can be set arbitrarily using a code.
Setting
Function
0,1,2,3 Multistep frequency selection (1 to 15
steps)
4 Acceleration/deceleration selection (1
step)
5 Self holding selection [HLD]
6 Coast-to-stop command [BX]
7 Error reset [RST]
8 External alarm [THR]
9 Frequency setting 2 / frequency setting
1 [Hz2 / Hz1]
10 Motor 2 / motor 1 [M2 / M1]
11 DC brake command [DCBRK]
12 Torque limit 2 / torque limit 1 [TL2 /
TL1]
13 UP command [UP]
14 DOWN command [DOWN]
15 Write enable for keypad (data change
allowed) [WE-KP]
16 PID control cancel [Hz / PID]
17 Forward/reverse operation switch
(terminal 12 and terminal C1) [IVS]
18 Link operation selection
(RS485 standard, BUS Option) [LE]
Note) The data numbers not assigned to E01
through E05 are considered to be inactive.
Multistep frequency
Frequencies set to function codes C05 through
C19 can be selected according to external digital
input signal switching. Set data 0 to 3 to the
desired digital input terminals and combination of
input signals determines the selected frequency.
Multistep frequency selection
Combination of input
signals
3
[SS8]
2
[SS4]
1
[SS2]
0
[SS1]
Selected frequency
off off off off
Selected by F01 or C30
off off off on
C05 Multistep frequency 1
off off on off
C06 Multistep frequency 2
off off on on
C07 Multistep frequency 3
off on off off
C08 Multistep frequency 4
off on off on
C09 Multistep frequency 5
off on on off
C10 Multistep frequency 6
off on on on
C11 Multistep frequency 7
on off off off
C12 Multistep frequency 8
on off off on
C13 Multistep frequency 9
on off on off
C14 Multistep frequency 10
on off on on
C15 Multistep frequency 11
on on off off
C16 Multistep frequency 12
on on off on
C17 Multistep frequency 13
on on on off
C18 Multistep frequency 14
on on on on
C19 Multistep frequency 15
Acceleration/deceleration time selection
Acceleration/deceleration time set to function
codes E10 and E11 can be selected according to
external digital input signal switching.
Input signal
4[RT1]
Selected
acceleration/deceleration time
off
F07 Acceleration time 1
F08 Deceleration time 1
on
E10 Acceleration time 2
E11 Deceleration time 2
3-wire operation stopcommand [HLD]
Used for three-wire operation. When HLD-P24 is
ON, the FWD or REV signal is maintained, and
when it is OFF, the signal is reset.
ON ON
ON ON
ON ON
FW D-CM
REV-CM
HLD-CM
Output
frequency
Forward
Reverse
Ignored
Note : The inverter operates while FWD-P24 or
REV-P24 is ON even if HLD-P24 is OFF. An
external interlock sequence ,which makes
FWD-P24 and REV-P24 OFF when HLD-P24 is
OFF, is required.
P24
P24
P24
