Fuji Electric FVR-E11S-7EN

5-26
C: Control Functions of Frequency
C01
Jump frequency 1
C02 Jump frequency 2
C03 Jump frequency 3
C04 Jump frequency hysteresis
 These functions jump the inverter output frequency at the set frequencies to avoid mechanical
resonance with the load.
 Three jump frequencies can be set.
 This function is inactive when all the jump frequencies 1 through 3 are set at 0 Hz.
 The frequencies are not jumped during acceleration or deceleration.
If the setting ranges of jump frequencies overlap, the sum of the setting ranges is jumped.
C01 C02 C03
Setting range: 0 to 400 Hz
Minimum unit: 1 Hz
C04
Setting range: 0 to 30 Hz
Minimum unit: 1 Hz
Jump frequency
width
Jump frequency 1
Jump frequency width
Jump frequency 2
Jump frequency width
Jump frequency 3
Output frequency (Hz)
Frequency setting (Hz)
０
Jump
frequency
width
Output frequency (Hz)
Actual jump
width
Jump frequency 1
Jump frequency 2
Frequency setting (Hz)
０
