5-39
H40
Maximum temperature of heat sink
The maximum value in each hour is displayed
in degree C.
H41 Maximum effective current
The maximum value in each hour is displayed
in A.
H42 Main circuit capacitor life
The capacity of the capacitor in the main circuit
is displayed in %. For the measuring conditions,
refer to section 8-2 (1) "Measurement of
capacitance of capacitor in main circuit".
H43 Cooling fan operation time
Integral hours is displayed. The displayed time
is 0 to 6500, indicating 0 to 65000 hours.
(Though the displayed value is in ten hours, the
inverter adds each hour. Operation shorter than
one hour is not counted.)
H44 Inverter ROM version
The version of the software of the inverter is
displayed.
H45 Keypad panel ROM version
The version of the software of the keypad panel
is displayed.
H46 Option ROM version
For inverters with optional equipment, the
version of the optional software is displayed.
A: Alternative motor parameters
A01 Maximum frequency 2
The maximum frequency output by the inverter for
motor 2. This parameter functions in the same way
as F03 "Maximum output frequency 1". For the
description, refer to F03 "Maximum output
frequency 1".
A02 Base frequency 2
The maximum output frequency in the constant
torque zone of motor 2, that is, the output
frequency at the rated output voltage. This
parameter functions in the same way as F04
"Base frequency 1". For the description, refer to
F04 "Base frequency 1".
A03 Rated voltage 2 (at base frequency 2)
The rated output voltage supplied to motor 2. This
parameter functions in the same way as F04
"Rated voltage 1". For the description, refer to F05
"Rated voltage 1".
A04 Maximum voltage 2 (at maximum
frequency 2)
The maximum output voltage of the inverter for
motor 2. This parameter functions in the same way
as F06 "Maximum voltage 1". For the description,
refer to F06 "Maximum voltage 1".
A05 Torque boost 2
The torque boost function of motor 2. This
parameter functions in the same way as F09
"Torque boost 1". For the description, refer to F09
"Torque boost 1".
A06 Electronic thermal overload relay for
motor 2 (Select)
A07 Electronic thermal overload relay for
motor 2 (Level)
A08 Electronic thermal overload relay for
motor 2 (Thermal time constant)
The electronic thermal overload relay functions of
motor 2. These parameters function in the same
way as F10 through F12 Electronic thermal
overload relay for motor 1. For the description,
refer to F10 through F12.
A09 Torque vector control 2
The torque vector function of motor 2. This
parameter functions in the same way as F42
"Torque vector control 1". For the description, refer
to F42 "Torque vector control 1".
A10 Number of motor 2 poles
The number of poles of driven motor 2. This
parameter functions in the same way as P01
"Number of motor 1 poles". For the description,
refer to P01 "Number of motor 1 poles)".
