Fuji Electric MICREX-F Series User Manual

MICREX-F Series SIO Driver
GP-Pro EX Device/PLC Connection Manual
10
(5) Create the default file in the data table. Please refer to the manual of the External Device for the default file
number or the setting method. When you select MODE2 or 3, use the rotary switch to specify the same
number as the station No. in the device setting. The setting is not necessary for MODE1 (RS232C 1:1
connection). Please refer to the connection configuration diagrams for more details.
(6) Select [Transfer] from the [File] menu to transfer to the External Device body.
(7) After the transfer is completed, restart the External Device.
Setup Items Setup Description Notes
MODE switch Depending on connection type
Set by the rotary switch
Station No. Depending on connection type
Transmission Procedure No procedure
Set by the initial file
Mode Settings
Baud rate 19200
Data Bit 7
Parity Bit Even
Stop Bit 2
DCE/DTE DCE
CTS/RTS Always ON
DSR/DTR Always ON
Send Condition None
PK Access Enable
Transmission Code JIS
Code Conversion Enable
Head Code STX
End Code ETX
Head Code 1, 2 0
End Code 1, 2 0
BCC None
