2 Product Overview
28
Product Overview
2
9 Push-button power switch Switches the power of the machine on and off.
Note • If the main power is not switched on, the machine will not be powered on
even when the power is switched on. For more information, refer to
"Power Source" (P.29)
.
10 <Start> button Press this button to start scanning a document.
11 <Error> indicator Blinks if a system error occurs.
This indicator lights up when a problem other than a system error occurs
with the machine, including paper jams and running out of paper or toner.
If the <Error> indicator blinks, contact our Customer Support Center.
12 <Data> indicator Blinks when the machine is sending or receiving data to or from a client.
This indicator lights up when data is stored in the machine's memory, when
received faxes are waiting to be printed, or when faxes are stored in a folder.
13 <Main Power> indicator Lights up when the main power is switched on.
Note • If the main power is not switched on, the machine will not be powered on
even when the power is switched on.
14 <Dial Pause> button Press this button to insert a pause into a destination number.
15 <Speed Dial> button Press this button to specify a recipient with an address number when
sending a fax or e-mail.
16 <C (Clear)> button Press this button to cancel a numerical value you have entered with the
numeric keypad.
17 Numeric keypad Use the numeric buttons on the keypad to enter the number of copies,
passcodes, and other numerical values.
18 <Services Home> button Press this button to display the Services Home screen.
19 <Custom Button 1> (Copy) "Copy" is assigned to this button by default.
Press this button to display the [Copy] screen.
20 <Custom Button 2> (Fax) "Fax" is assigned to this button by default.
Press this button to display the [Fax] screen.
21 <Custom Button 3> (Review) "Review" is assigned to this button by default.
On the [Review] screen, you can check a list of the status of Copy, Fax, and
Scan services whose settings have been changed from the defaults. You can
also check the details of fax and e-mail recipients.
No. Component Function
