16 Appendix
620
Appendix
16
* : Finisher-A1 cannot be installed for ApeosPort-IV C5575/C4475 or DocuCentre-IV C5575/C4475.
îš„ Finisher-B1 (optional)
Paper Size/Paper Weight Finisher trayMaximum : A3, 11 x 17"
Minimum : Postcards (100x148mm), 55 - 220 gsm
Stacker Capacity Finisher tray (For paper not stapled)
A4 : 500 sheets,
B4 : 250 sheets,A3 or larger:200 sheets
Mixed stack* : 250 sheets
Finisher tray (For paper stapled)
30 sheets
* : Based on when larger size paper is stacked on paper.
Important • When using 80 gsm paper
Staple Capacity : A4 : 50 sheets (90 gsm or less),
B4 or larger : 30 sheets (90 gsm or less)
Paper Size : Maximum A3, 11 x 17" / Minimum B5
Position : 1 place (front/angled stapling)
Important • When using 80 gsm paper
Dimensions/Weight Width 559 x Depth 448 x Height 246 mm, 12 kg
Space Requirement (when
connected to the main
unit)
Width 1,129 x Depth 699 mm (main unit + Finisher-A1, when the
extension tray and the bypass tray are fully extended)
Type Finisher tray x 1 : Sorting (Offset available)/
Stacking (Offset available)
Paper Size/Paper Weight Finisher tray Maximum: A3, 11 x 17"
Minimum: B5, 55 - 220 gsm
Stacker Capacity Finisher tray (For paper not stapled)
A4 : 2,000 sheets
B4 or larger : 1,000 sheets
Mixed stack*1 : 300 sheets
Finisher tray(For paper stapled)
A4 : 100 sets or 1,000 sheets
B4 or larger : 75 sets or 750 sheets
Center binding/folding*2 : 50 sets or 600 sheets
Folding*2 : 500 sheets
Important • When using 80 gsm paper
Staple Capacity : 50 sheets (90 gsm or less)
Paper size :Maximum :A3, 11 x 17",
Minimum : B5
Position : 1 place (front: angled stapling, back: straight stapling),
2 places (parallel stapling)
Important • When using 80 gsm paper
Punch*3
Paper size : A3, 11 x 17", B4, A4, A4 , 8.5 x 11",
8.5 x 11" , B5
Number of Holes : 2/4 holes, or US 2/3 holes
Paper Weight : 55 - 200 gsm
Important • When using 80 gsm paper
To Next Page
