16 Appendix
702
Appendix
16
Position
adjustment
113
(Vertical
position
adjustment)
Adjusts the hard clip area vertically or horizontally. You can set from -250 mm
to +250 mm in 1 mm increments.
[0] (Default) : Does not move the hard clip area.
[1] - [250] : -250 to -1 mm
[251] - [500] : +1 to +250 mm
Important • Data outside the printable area is not printed regardless of the adjustment
of the print position. In addition, data moved outside the printable area as
a result of adjusting the print position is not printed.
114
(Horizontal
position
adjustment)
Number of sets 115 Sets the method for specifying the print sets.
[0] (Default) : Protocol
[1] : Panel
[2] : Command
Print control 150
(HP-GL mode)
Selects a graphics language. This setting affects to IW, OW, and UC of HP-GL/
2 commands.
[0] (Default) : HP-GL
[1] : HP-GL/2
Note • To print HP-GL/2 command that does not include BP command, select [HP-
GL/2].
151
(Hard clip)
Sets the size of hard clip area.
In HP-GL mode, the plottable area is determined in line with the paper size,
apart from the printable area. This area is called the "hard clip area", and
determines the maximum range of pen movement. Accordingly, images
cannot be drawn outside the boundary of the hard clip area.
[0] : Standard
[2] (Default) : Paper
For more information on hard clip area, refer to "Hard Clip Area" (P.705).
152 (Eject
command SP)
Sets the command that indicates the end of plotting. When the command
specified here is received, plotting is terminated and the paper is output.
[0] (Default) : OFF
[1] : ON
The default value is [ON] for SPO, and [OFF] for the others.
Note • If multiple commands are specified, when one of the commands is
received, plotting is terminated and the paper is output.
153 (Eject
command
SPO)
154 (Eject
command NR)
155 (Eject
command FR)
156 (Eject
command PG)
157 (Eject
command AF)
158 (Eject
command AH)
Parameter Item No. Value
