20 2 Setting the HP-GL Mode
Paper Margin
Sets the paper margin for auto scaling.
The position can be specified within the range 0 to 99 mm in 1 mm increments (0.0 to
3.9 inch in 0.1 inch increments). Default is [0mm].
If entering the value in inches, enter it within 0 to 3.9" in increments of 0.1". The default is
[0.0"].
Note
• When changing candidate values with the < > or < > button, you can change the display
continuously by holding the button down. Pressing the < > and < > buttons simultaneously displays
default.
Image Enhancement
Enables or disables image enhancement.
Image enhancement raises the resolution and smooth sharp edges.
Candidate values are shown below.
[On] (default)
[Off]
Important
• The [Zoom Mode], [Area Determine], and [Paper Margin] settings are effective only when [File Size] is
set to [Auto].
Emulation Target
Sets the printer to be used for emulation.
Candidate values are shown below.
[HP750C] (default)
Emulates HP750C.
[FX4036]
Emulates FX4036.
Pen Attributes
Sets attributes of 16 pens ([No. 00] through [No. 15]).
It specifies the line thickness and color.
Pen Width
Sets the pen width (thickness). The pen width can be specified within the range 0.0 to
25.5 mm in 0.1 mm increments (0.00 to 1.00 inch in 0.01 inch increments). Default is
[0.3mm].
If entering the value in inches, enter it within 0.00 to 1.00" in increments of 0.01". The default
is [0.01].
Note
• When changing candidate values with the < > or < > button, you can change the display
continuously by holding the button down. Pressing the < > and < > buttons simultaneously displays
default.
• When an image is reduced by combining the [File Size] setting and [Output Size] setting, the pen width
is also reduced (minimum pen width = 0.1 mm (0.01")).
• The line width is increased starting in the center of the line.
• When 0.0 mm (0.0") is specified, nothing is drawn.
To Next Page
