Printer Connection and Software Installation 59
Identifying Print Driver Pre-install Status (for Network
Connection Setup)
Before installing print drivers on your computer, print the System Settings page to check the IP
address of your printer.
This section includes:
• "Using the Operator Panel" on page 59
• "Using the Printer Setting Utility" on page 59
• "Disabling the Firewall Before Installing Printer Drivers" on page 60
Using the Operator Panel
NOTE:
• The reports and lists are all printed in English.
1 Press the (Menu) button.
2 Select Report/List, and then press the button.
3 Select System Settings, and then press the button.
The System Settings page is printed.
4 Find the IP address under Wired Network (DocuPrint P255 d) or Wired Network/Wireless
Network (DocuPrint P255 dw) on the System Settings page.
If the IP address is 0.0.0.0, wait for a few minutes to resolve the IP address automatically, and
then print the System Settings page again.
If the IP address is not resolved automatically, see "Assigning an IP Address (for IPv4 Mode)" on
page 54.
Using the Printer Setting Utility
The following procedure uses Windows 7 as an example.
NOTE:
• The reports and lists are all printed in English.
1 Click Start All Programs Fuji Xerox Fuji Xerox Printer Software for Asia-Pacific
your printer Printer Setting Utility.
NOTE:
• The window to select a printer appears in this step when multiple print drivers are installed on your
computer. In this case, click the name of the desired printer listed in Printer Name.
The Printer Setting Utility starts.
2 Click the Printer Settings Report tab.
3 Select TCP/IP Settings from the list on the left side of the page.
The TCP/IP Settings page is displayed.
If the IP address shows 0.0.0.0 (the factory default) or 169.254.xx.xx, an IP address has not been
assigned. To assign one for your printer, see "Assigning an IP Address (for IPv4 Mode)" on page 54.
