Mainboard D1522 / D1521
A26361-D1522-Z120-3-6319 English - 3
List of features
Onboard features D1522-A D1521-A
Chipset i845GE i845GE
Board size µ-ATX µ-ATX
VGA !!
Audio !!
Buzzer / int. Speaker Support - / ! - / !
LAN / with Alert-on-LAN ! / !! / -
HI-SPEED USB 2.0 !!
SmartCard Reader Support (USB / serial) ! / - - / -
Temperature monitoring ! -
System Monitoring ! -
Fujitsu Siemens Computers Keyboard Power
Button Support
!!
Internal ports
DIMM Sockets (DDR SDRAM, PC2100/1600) 22
AGP Slot (2/4x, 32 bit, 66 MHz, 1.5 V) 11
PCI slot (32 bit, 33 MHz, 5 V and 3.3 V) 33
CNR Slot (Type A, AC‘97 only) --
IDE Interface (Ultra DMA/100) 22
Floppy Interface (up to 2.88 MB) 11
S/PDIF* (digital audio) 11
CD / AUX audio input 1 / - 1 / -
Frontpanel Audio (headphone, microphone) 11
Wake On LAN --
USB Ports* (2.0, ~480 Mb/s) 44
Serial Ports* (FIFO, 16550 compatible) 11
Fan Connectors PSU** / FAN1 / FAN2 / FAN3 1 / 1 / 1 / - - / 1 / 1 / -
SMBus Connector* (Case Temperature) 1-
Intrusion Connector* (Case Open) 1-
Power Connectors ATX / ATX12V / AGP PRO 1 / 1 / - 1 / 1 / -
