Basisinformationen Mainboard
A26361-D2000-Z120-1-7419, edition 3 English - 7
External ports
The locations of the external connections are usually marked with the following symbols.
PS/2 keyboard port, purple
Audio input (Line in), light blue
Serial interface, turquoise
PS/2 mouse port, green
Monitor port, blue
Parallel port/Printer, burgundy
LAN
LAN port
USB - Universal Serial Bus, black
Audio output (Line out), light green
Microphone jack (mono), pink
1394
FireWire, grey
S/PDIF
digital 6-channel audio output, orange
