Add-on modules / Upgrading
24 - English A26361-D2000-Z120-1-7419, edition 3
Upgrading main memory
Information on equipment, memory modules, module sizes and memory expansion is contained in
the "Short Description" manual.
A current list of the memory modules recommended for this mainboard is available on the Internet at:
www.fujitsu-siemens.com.
Installing a memory module
2
2
► Push the holders on each side of the memory slot outwards.
► Insert the memory module into the location (1).
► At the same time flip the lateral holders upwards until the memory module snaps in place (2).
Removing a memory module
1
1
► Push the clips on the right and left of the memory slot outward (1).
► Pull the memory module out of the memory slot (2).
