Preparation for use and operation Using the power-management features
32 A26391-K96-Z100-2-7619
Disabling Standby mode:
any key
i
Note on Windows 98:
Ê Switch the notebook on.
The notebook reverts to the status (programs) it had prior to switching into Suspend
mode.
Suspend mode
In Suspend mode, all current data (active programs, files) is buffered in the memory (Suspend to
DRAM) or saved to the hard disk (Suspend to Disk), and then the notebook is switched off. After the
notebook is switched on, you can continue working exactly where you left off before.
i
In Suspend to DRAM mode the power-on indicator flashes (1 second on/3 seconds off).
Suspend to Disk mode is not indicated.
Enabling Suspend mode
[Fn]
[Fn][Fn]
[Fn] + [F4]
[F4][F4]
[F4]
or
Ê Hold the on/off switch pressed for approximately one second.
!
If your notebook is in Suspend mode:
• do not connect any external peripheral devices
• do not disconnect any external peripheral devices
• do not attempt to switch it on if the built-in battery is flat
• do not change or remove the floppy disk, if inserted
• do not add or remove RAM
• do not add or remove any PC card.
Suspend to DRAM
The current data is buffered in the memory (DRAM). The data is stored for as long as the notebook
is supplied with energy. If the battery is full, the data is stored for a matter of days. Without a battery
and without a power supply the current data is lost.
Suspend to Disk
The active data can only be saved if sufficient space is available on the hard disk (at least the main
memory size + 2 Mbytes). If the operating system Windows NT or OS/2 Warp is used, a FAT
partition with this space must be created as a drive on the hard disk (see manual for respective
operating system).
Ending Suspend mode
Ê Switch the notebook on.
The notebook reverts to the status it had prior to switching into Suspend mode.
