Technical data
54 A26391-K96-Z100-2-7619
Ports
• PS/2 mouse port/
PS/2 keyboard port:
6-pin mini DIN female connector
• Parallel port: 25-pin female connector, bi-directional, EPP
ECP capable
• Port for external monitor: 15-pin female connecto
• Serial port: 9-pin male connector, 16550 compatible
• Microphone jack: connector, mono
• Headphones outlet: connector, stereo
• Modem connector, RJ11
• USB (Universal Serial Bus)
• Kensington Lock
Environmental conditions
Environment class 7K1 DIN IEC 721
Environment class 7M2 DIN IEC 721
Temperature:
• Operating (7K1) 5 °C .... 35 °C
• Transport (2K2) -25 °C .... 60 °C
Dimensions
Width/depth/height: 310 mm/250 mm/45 mm
Weight: approx. 3.3 kg
Battery
Rated voltage: 9.6 V
Rated capacity 38.4 Wh
Charging time (when not in operation): 2 hours (in the off state)
Operating time with a battery: between 2 and 3.5 hours roughl
(depending on application)
Weight: 550 g
Power supply unit
Primary
• Rated voltage: 100 V to 240 V (automatic)
• Frequency: 50 Hz to 60 Hz (automatic)
• max. rated current: 1.5 A
Secondary
• Rated voltage: 19 V
• max. rated current: 3.15 A
