Connecting external devices
50 A26391-K96-Z100-2-7619
Ports
DC-IN
Modem port
Parallel port
Serial port
Monitor port
Headphone port:
Microphone jack (mono)
PS/2 mouse port / keyboard port
USB - Universal Serial Bus
DC IN DC socket
Connecting devices with serial or parallel port
(printer)
Ê Connect the data cable of the external device to the appropriate port.
Connecting an external monitor
You can connect an external VGA, SVGA or XGA screen. The notebook screen controller for an
external monitor supports screen resolutions up to 1024 x 768 with 65.536 colors (16 bits). If you
wish to use a resolution greater than 640 x 480, you must load the relevant display drivers (see the
manuals supplied with your display).
Ê Plug the data cable of the monitor into the monitor port.
Ê Connect the power cable of the external monitor to a power outlet and switch on the monitor.
Ê Switch the notebook on.
Ê Press the key combination [Fn]
[Fn][Fn]
[Fn] + [F12]
[F12][F12]
[F12] (selecting internal/external display).
Ê Select the resolution for the external monitor.
