Names of controls and parts
161616
◆ Names of controls and parts
Front view
※NOTE : Double function button → "E-COM" & "MUTE" functions
Though the words "press" and "tap" are used in the text for the
operation of the [ TU ] button and [ BND ] button, the
button is actually slid in the or direction.
With the front open
● Caution ●
Never place an object or rest your hands or the like on the
front panel.
Disc slot
[MODE] button
[CUSTOM] button
[RESET] button[AUDIO CONTROL]
button
Buttons [1] to [6]
[FUNC] button
[OPEN] button
[E-COM] button
[ BND ] button
[ TU ]
button
[SOURCE] button
