8-3. ELECTRIC CHARACTERISTICS
Model Name
AB A18L AB A24L
Voltage V
Frequency Hz
Max Operating Current A 0.5 0.7
Circuit breaker A 0.6 0.9
Connection Cable
mm
2
1.5 - 2.5 1.5 - 2.5
Limited wiring length m 26 31
*1)Wiring Spec.
Power Supply
230
50
Model Name AO A18L AO A24L
Voltage V
Frequency Hz
Max Operating Current A 15.0 16.2
Starting Current A 7.7 10.0
Main Fuse (Circuit breaker)
Current
A 20 20
Power Cable
mm
2
*2)Limited wiring length m 24 22
*1) Wiring Spec.
Selected Sample
(Selected based on Japan Electrotechnical Standard and Codes Committee E0005)
*2) Limited Wiring length :
This is the wiring length in case voltage descent is less than 2%.
When the wiring length becomes long, please select the wiring of a more larger diameter.
Power Supply
*1) Wiring Spec.
230
50
3.5 - 4.5
Model name
AB A36L AB A45L
Voltage V
Frequency Hz
Max. operating current (Indoor unit) A 0.7 0.8
Connection cable
mm
2
1.5-2.5 1.5-2.5
Limited wiring length m 51 51
Power supply
230
50
Wiring spec.
(Indoor unit to outdoor unit)
Model Name AO A36L AO A45L
Voltage V
Frequency Hz
Max. Operating Current A 19.0 20.0
Starting Current A
Main Fuse (Circuit breaker)
Current
A
Power Cable
mm
2
*2)Limited wiring length m
Power Supply
*1) Wiring Spec.
230
50
5.3 - 6.0
30
17
15.0
