02-04
MODEL : ABTA36 / 45LATN
(Unit : mm)
Top view
Side view
Rear view
1 2 3
45
6
30 30
Suspension bolt pitch
1,600
INDOOR UNIT (Top view)
Dimensions
(Space Required
for Installation)
10
155
300
INDOOR UNIT
Suspension bolt
should extend
outward 30 to 75.
1
Refrigerant piping flare connection (Gas)
Refrigerant piping flare connection (Liquid)
Drain piping connection
Knock out hole for fresh air
Knock out hole for refrigerant piping
Hole for lifting bolt (Use M10 screw bolt)
2
3
4
5
6
