1-2. For AB*A36/ 45LATN
Following table shows the fan speed of the outdoor unit.
The outdoor fan speed changs in the range mentioned avobe depending on the compressor
frequency and outdoor temperature.
It runs at 500rpm for 20 seconds after starting up the outdoor fan.
When the outdoor heat exchanger temperature is lower than 2°C,
the fan speed switches to 850rpm(Upper fan) and 750rpm(Lower fan) on heating mode.
05-08
Table 8 : Fan speed of the outdoor unit
AB*A36/ 45LATN have two fan motors.
Cooling
Heating
Upper fan
Lower fan
850/ 780/ 520/ 400/ 350/ 300/ 280 rpm 850/ 780/ 350/ 200/ 170/ 150 rpm
780/ 750/ 350/ 200/ 170/ 150 rpm
780/ 750/ 520/ 350/ 280/ 0 rpm
AB*A36LATN
AB*A45LATN
