Fujitsu ACUH07LUAS1 - Model: ADUH18 LUAS1

¢
Model: ADUH18LUAS1
Unit: in (mm)
Rear view
View A
Top view
Side view
Front view
Bottom view
Drain port
2 (51)
30-1/2 (774)
6-7/8 (174)
2-13/16 (71)
6 (152)
3-7/16
(87)
2-3/16
(56)
33-7/16 (850)
36-3/4 (934)
3-15/16 (100) × 8 = 31-1/2 (800)
1-3/16 (30)
14-13/16 (377)
6-7/16
(163)
4-11/16 (119)
3-1/2 (89)
3-1/16 (78)
2-3/16 (55)
1-7/8 (47)
3/8 (10)
24-7/16 (620)
14-5/8 (371)
10-3/8 (264)
5-11/16
(144)
2-11/16
(69)
33-7/16 (850)
34 (864)
35-7/16 (900)
1-11/16 (43)
1-1/4
(31)
7-13/16
(198)
6-5/8
(168)
5-15/16
(151)
3-1/16
(78)
2-3/16 (55)
A
- 16 -
3-2. Slim duct type 3. Dimensions
MULTI-SPLIT TYPE 5-unit type
MULTI-SPLIT TYPE 5-unit type
