Fujitsu ACUH07LUAS1 User Manual

¢ Wall mounted type
 Unit: kBtu/h, °F
• TC: Total Capacity (kBtu/h), SHC: Sensible Heat Capacity (kBtu/h).
• The data is based on the following conditions.
• Pipe length: 24.6 ft (7.5 m), Height difference: 0 ft (0 m) [Outdoor unit - Indoor unit]
MODEL: ASU7RLF1
Outdoor temperature
Indoor temperature (°FDB / °FWB)
64.0 / 54.0 70.0 / 60.0 75.0 / 63.0 80.0 / 67.0 85.0 / 71.0 90.0 / 73.0
(°FDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
14.0 5.88 4.12 6.65 4.70 7.01 5.41 7.50 6.08 8.02 6.64 8.27 7.61
23.0 5.88 4.12 6.65 4.70 7.01 5.41 7.50 6.08 8.02 6.64 8.27 7.61
32.0 5.88 4.12 6.65 4.70 7.01 5.41 7.50 6.08 8.02 6.64 8.27 7.61
41.0 5.88 4.12 6.65 4.70 7.01 5.41 7.50 6.08 8.02 6.64 8.27 7.61
50.0 5.88 4.12 6.65 4.70 7.01 5.41 7.50 6.08 8.02 6.64 8.27 7.61
59.0 5.88 4.12 6.65 4.70 7.01 5.41 7.50 6.08 8.02 6.64 8.27 7.61
67.0 5.88 4.12 6.65 4.70 7.01 5.41 7.50 6.08 8.02 6.64 8.27 7.61
77.0 5.88 4.12 6.65 4.70 7.01 5.41 7.50 6.08 8.02 6.64 8.27 7.61
87.0 5.88 4.12 6.65 4.70 7.01 5.41 7.50 6.08 8.02 6.64 8.27 7.61
95.0 5.88 4.12 6.65 4.70 7.01 5.41 7.50 6.08 8.02 6.64 8.27 7.61
104.0 5.11 3.12 5.78 3.55 6.09 4.09 6.52 4.60 6.97 5.03 7.19 5.76
115.0 4.35 2.25 4.92 2.57 5.18 2.96 5.55 3.32 5.93 3.64 6.11 4.17
MODEL: ASU9RLF1
Outdoor temperature
Indoor temperature (°FDB / °FWB)
64.0 / 54.0 70.0 / 60.0 75.0 / 63.0 80.0 / 67.0 85.0 / 71.0 90.0 / 73.0
(°FDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
14.0 7.53 5.27 8.51 6.01 8.97 6.92 9.60 7.78 10.26 8.50 10.58 9.74
23.0 7.53 5.27 8.51 6.01 8.97 6.92 9.60 7.78 10.26 8.50 10.58 9.74
32.0 7.53 5.27 8.51 6.01 8.97 6.92 9.60 7.78 10.26 8.50 10.58 9.74
41.0 7.53 5.27 8.51 6.01 8.97 6.92 9.60 7.78 10.26 8.50 10.58 9.74
50.0 7.53 5.27 8.51 6.01 8.97 6.92 9.60 7.78 10.26 8.50 10.58 9.74
59.0 7.53 5.27 8.51 6.01 8.97 6.92 9.60 7.78 10.26 8.50 10.58 9.74
67.0 7.53 5.27 8.51 6.01 8.97 6.92 9.60 7.78 10.26 8.50 10.58 9.74
77.0 7.53 5.27 8.51 6.01 8.97 6.92 9.60 7.78 10.26 8.50 10.58 9.74
87.0 7.53 5.27 8.51 6.01 8.97 6.92 9.60 7.78 10.26 8.50 10.58 9.74
95.0 7.53 5.27 8.51 6.01 8.97 6.92 9.60 7.78 10.26 8.50 10.58 9.74
104.0 6.55 3.99 7.40 4.55 7.80 5.24 8.35 5.88 8.93 6.44 9.20 7.37
115.0 5.57 2.89 6.29 3.29 6.63 3.79 7.10 4.26 7.59 4.65 7.83 5.33
MODEL: ASU12RLF1
Outdoor temperature
Indoor temperature (°FDB / °FWB)
64.0 / 54.0 70.0 / 60.0 75.0 / 63.0 80.0 / 67.0 85.0 / 71.0 90.0 / 73.0
(°FDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
14.0 10.04 6.60 11.34 7.52 11.96 8.66 12.80 9.73 13.68 10.64 14.11 12.19
23.0 10.04 6.60 11.34 7.52 11.96 8.66 12.80 9.73 13.68 10.64 14.11 12.19
32.0 10.04 6.60 11.34 7.52 11.96 8.66 12.80 9.73 13.68 10.64 14.11 12.19
41.0 10.04 6.60 11.34 7.52 11.96 8.66 12.80 9.73 13.68 10.64 14.11 12.19
50.0 10.04 6.60 11.34 7.52 11.96 8.66 12.80 9.73 13.68 10.64 14.11 12.19
59.0 10.04 6.60 11.34 7.52 11.96 8.66 12.80 9.73 13.68 10.64 14.11 12.19
67.0 10.04 6.60 11.34 7.52 11.96 8.66 12.80 9.73 13.68 10.64 14.11 12.19
77.0 10.04 6.60 11.34 7.52 11.96 8.66 12.80 9.73 13.68 10.64 14.11 12.19
87.0 10.04 6.60 11.34 7.52 11.96 8.66 12.80 9.73 13.68 10.64 14.11 12.19
95.0 10.04 6.60 11.34 7.52 11.96 8.66 12.80 9.73 13.68 10.64 14.11 12.19
104.0 8.73 4.99 9.87 5.69 10.40 6.55 11.13 7.36 11.90 8.05 12.27 9.22
115.0 7.42 3.61 8.39 4.12 8.84 4.74 9.47 5.32 10.12 5.82 10.43 6.67
MODEL: ASU15RLF1
Outdoor temperature
Indoor temperature (°FDB / °FWB)
64.0 / 54.0 70.0 / 60.0 75.0 / 63.0 80.0 / 67.0 85.0 / 71.0 90.0 / 73.0
(°FDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
14.0 12.54 8.14 14.18 9.28 14.94 10.68 16.00 12.00 17.10 13.12 17.63 15.04
23.0 12.54 8.14 14.18 9.28 14.94 10.68 16.00 12.00 17.10 13.12 17.63 15.04
32.0 12.54 8.14 14.18 9.28 14.94 10.68 16.00 12.00 17.10 13.12 17.63 15.04
41.0 12.54 8.14 14.18 9.28 14.94 10.68 16.00 12.00 17.10 13.12 17.63 15.04
50.0 12.54 8.14 14.18 9.28 14.94 10.68 16.00 12.00 17.10 13.12 17.63 15.04
59.0 12.54 8.14 14.18 9.28 14.94 10.68 16.00 12.00 17.10 13.12 17.63 15.04
67.0 12.54 8.14 14.18 9.28 14.94 10.68 16.00 12.00 17.10 13.12 17.63 15.04
77.0 12.54 8.14 14.18 9.28 14.94 10.68 16.00 12.00 17.10 13.12 17.63 15.04
87.0 12.54 8.14 14.18 9.28 14.94 10.68 16.00 12.00 17.10 13.12 17.63 15.04
95.0 12.54 8.14 14.18 9.28 14.94 10.68 16.00 12.00 17.10 13.12 17.63 15.04
104.0 10.91 6.16 12.33 7.02 13.00 8.08 13.92 9.08 14.88 9.93 15.34 11.38
115.0 9.28 4.45 10.49 5.08 11.05 5.84 11.84 6.57 12.65 7.18 13.04 8.23
- 266 -
6-2. Cooling capacity 6. Capacity table
OUTDOOR UNIT AOU45RLXFZ OUTDOOR UNIT AOU45RLXFZ

Fujitsu ACUH07LUAS1 Specifications

General

Brand	Fujitsu
Model	ACUH07LUAS1
Category	Air Conditioner
Language	English
