Fujitsu ACUH07LUAS1 User Manual

Indoor unit connect-
ing capacity
Outdoor temperature
Indoor temperature
64 °FDB 70 °FDB 75 °FDB 80 °FDB 85 °FDB 90 °FDB
54 °FWB 60 °FWB 63 °FWB 67 °FWB 71 °FWB 73 °FWB
kBtu/h °FDB TC IP TC IP TC IP TC IP TC IP TC IP
41
14
34.3 1.51 38.7 1.53 40.8 1.55 43.7 1.56 46.8 1.58 48.2 1.59
23 34.3 1.50 38.7 1.53 40.8 1.54 43.7 1.56 46.8 1.57 48.2 1.58
32 34.3 1.49 38.7 1.52 40.8 1.53 43.7 1.55 46.8 1.56 48.2 1.57
41 34.3 1.66 38.7 1.69 40.8 1.70 43.7 1.72 46.8 1.74 48.2 1.75
50 34.3 1.83 38.7 1.86 40.8 1.88 43.7 1.90 46.8 1.92 48.2 1.93
59 34.3 2.52 38.7 2.57 40.8 2.59 43.7 2.62 46.8 2.65 48.2 2.66
67 34.3 3.21 38.7 3.27 40.8 3.29 43.7 3.33 46.8 3.37 48.2 3.39
77 34.3 3.54 38.7 3.60 40.8 3.63 43.7 3.67 46.8 3.71 48.2 3.73
87 34.3 3.86 38.7 3.93 40.8 3.96 43.7 4.01 46.8 4.05 48.2 4.08
95 34.3 4.13 38.7 4.20 40.8 4.23 43.7 4.28 46.8 4.33 48.2 4.35
104 29.8 3.83 33.7 3.90 35.5 3.93 38.0 3.97 40.7 4.02 41.9 4.04
115 25.4 3.54 28.7 3.60 30.2 3.63 32.4 3.67 34.6 3.71 35.7 3.73
40
14
33.5 1.45 37.8 1.48 39.9 1.49 42.7 1.50 45.6 1.52 47.0 1.53
23 33.5 1.44 37.8 1.47 39.9 1.48 42.7 1.50 45.6 1.51 47.0 1.52
32 33.5 1.44 37.8 1.46 39.9 1.47 42.7 1.49 45.6 1.51 47.0 1.51
41 33.5 1.60 37.8 1.63 39.9 1.64 42.7 1.66 45.6 1.68 47.0 1.69
50 33.5 1.76 37.8 1.79 39.9 1.81 42.7 1.83 45.6 1.85 47.0 1.86
59 33.5 2.43 37.8 2.47 39.9 2.49 42.7 2.52 45.6 2.55 47.0 2.56
67 33.5 3.09 37.8 3.14 39.9 3.17 42.7 3.21 45.6 3.24 47.0 3.26
77 33.5 3.40 37.8 3.46 39.9 3.49 42.7 3.53 45.6 3.57 47.0 3.59
87 33.5 3.72 37.8 3.78 39.9 3.82 42.7 3.86 45.6 3.90 47.0 3.92
95 33.5 3.97 37.8 4.04 39.9 4.07 42.7 4.12 45.6 4.17 47.0 4.19
104 29.1 3.69 32.9 3.75 34.7 3.78 37.1 3.82 39.7 3.87 40.9 3.89
115 24.7 3.40 28.0 3.46 29.5 3.49 31.6 3.53 33.7 3.57 34.8 3.59
39
14
32.6 1.39 36.9 1.42 38.9 1.43 41.6 1.45 44.5 1.46 45.8 1.47
23 32.6 1.39 36.9 1.41 38.9 1.42 41.6 1.44 44.5 1.45 45.8 1.46
32 32.6 1.38 36.9 1.40 38.9 1.41 41.6 1.43 44.5 1.45 45.8 1.45
41 32.6 1.54 36.9 1.56 38.9 1.58 41.6 1.59 44.5 1.61 45.8 1.62
50 32.6 1.69 36.9 1.72 38.9 1.74 41.6 1.76 44.5 1.78 45.8 1.79
59 32.6 2.33 36.9 2.37 38.9 2.39 41.6 2.42 44.5 2.45 45.8 2.46
67 32.6 2.97 36.9 3.02 38.9 3.05 41.6 3.08 44.5 3.12 45.8 3.13
77 32.6 3.27 36.9 3.33 38.9 3.36 41.6 3.39 44.5 3.43 45.8 3.45
87 32.6 3.57 36.9 3.64 38.9 3.67 41.6 3.71 44.5 3.75 45.8 3.77
95 32.6 3.82 36.9 3.88 38.9 3.91 41.6 3.96 44.5 4.00 45.8 4.03
104 28.4 3.54 32.1 3.61 33.8 3.63 36.2 3.67 38.7 3.72 39.9 3.74
115 24.1 3.27 27.3 3.33 28.7 3.35 30.8 3.39 32.9 3.43 33.9 3.45
38
14
31.8 1.34 35.9 1.36 37.9 1.37 40.5 1.39 43.3 1.40 44.7 1.41
23 31.8 1.33 35.9 1.35 37.9 1.36 40.5 1.38 43.3 1.40 44.7 1.40
32 31.8 1.32 35.9 1.35 37.9 1.36 40.5 1.37 43.3 1.39 44.7 1.40
41 31.8 1.47 35.9 1.50 37.9 1.51 40.5 1.53 43.3 1.55 44.7 1.56
50 31.8 1.63 35.9 1.65 37.9 1.67 40.5 1.69 43.3 1.71 44.7 1.71
59 31.8 2.24 35.9 2.28 37.9 2.30 40.5 2.32 43.3 2.35 44.7 2.36
67 31.8 2.85 35.9 2.90 37.9 2.92 40.5 2.96 43.3 2.99 44.7 3.01
77 31.8 3.14 35.9 3.19 37.9 3.22 40.5 3.26 43.3 3.29 44.7 3.31
87 31.8 3.43 35.9 3.49 37.9 3.52 40.5 3.56 43.3 3.60 44.7 3.62
95 31.8 3.66 35.9 3.73 37.9 3.76 40.5 3.80 43.3 3.84 44.7 3.86
104 27.6 3.40 31.2 3.46 32.9 3.49 35.3 3.53 37.7 3.57 38.9 3.59
115 23.5 3.14 26.6 3.19 28.0 3.22 30.0 3.25 32.1 3.29 33.0 3.31
37
14
30.9 1.28 35.0 1.30 36.9 1.31 39.5 1.33 42.2 1.34 43.5 1.35
23 30.9 1.27 35.0 1.30 36.9 1.31 39.5 1.32 42.2 1.34 43.5 1.34
32 30.9 1.27 35.0 1.29 36.9 1.30 39.5 1.31 42.2 1.33 43.5 1.34
41 30.9 1.41 35.0 1.44 36.9 1.45 39.5 1.46 42.2 1.48 43.5 1.49
50 30.9 1.56 35.0 1.58 36.9 1.60 39.5 1.61 42.2 1.63 43.5 1.64
59 30.9 2.14 35.0 2.18 36.9 2.20 39.5 2.22 42.2 2.25 43.5 2.26
67 30.9 2.73 35.0 2.78 36.9 2.80 39.5 2.83 42.2 2.86 43.5 2.88
77 30.9 3.01 35.0 3.06 36.9 3.08 39.5 3.12 42.2 3.15 43.5 3.17
87 30.9 3.28 35.0 3.34 36.9 3.37 39.5 3.41 42.2 3.45 43.5 3.46
95 30.9 3.51 35.0 3.57 36.9 3.60 39.5 3.64 42.2 3.68 43.5 3.70
104 26.9 3.25 30.4 3.31 32.1 3.34 34.3 3.38 36.7 3.42 37.8 3.43
115 22.9 3.00 25.9 3.06 27.3 3.08 29.2 3.12 31.2 3.15 32.2 3.17
36
14
30.1 1.22 34.0 1.25 35.9 1.26 38.4 1.27 41.0 1.28 42.3 1.29
23 30.1 1.22 34.0 1.24 35.9 1.25 38.4 1.26 41.0 1.28 42.3 1.28
32 30.1 1.21 34.0 1.23 35.9 1.24 38.4 1.26 41.0 1.27 42.3 1.28
41 30.1 1.35 34.0 1.37 35.9 1.38 38.4 1.40 41.0 1.42 42.3 1.42
50 30.1 1.49 34.0 1.51 35.9 1.53 38.4 1.54 41.0 1.56 42.3 1.57
59 30.1 2.05 34.0 2.08 35.9 2.10 38.4 2.12 41.0 2.15 42.3 2.16
67 30.1 2.61 34.0 2.65 35.9 2.68 38.4 2.70 41.0 2.74 42.3 2.75
77 30.1 2.87 34.0 2.92 35.9 2.95 38.4 2.98 41.0 3.01 42.3 3.03
87 30.1 3.14 34.0 3.19 35.9 3.22 38.4 3.26 41.0 3.29 42.3 3.31
95 30.1 3.35 34.0 3.41 35.9 3.44 38.4 3.48 41.0 3.52 42.3 3.54
104 26.2 3.11 29.6 3.17 31.2 3.19 33.4 3.23 35.7 3.26 36.8 3.28
115 22.3 2.87 25.2 2.92 26.5 2.95 28.4 2.98 30.4 3.01 31.3 3.03
35
14
29.3 1.17 33.1 1.19 34.9 1.20 37.3 1.21 39.9 1.23 41.1 1.23
23 29.3 1.16 33.1 1.18 34.9 1.19 37.3 1.20 39.9 1.22 41.1 1.23
32 29.3 1.15 33.1 1.18 34.9 1.18 37.3 1.20 39.9 1.21 41.1 1.22
41 29.3 1.29 33.1 1.31 34.9 1.32 37.3 1.34 39.9 1.35 41.1 1.36
50 29.3 1.42 33.1 1.44 34.9 1.46 37.3 1.47 39.9 1.49 41.1 1.50
59 29.3 1.95 33.1 1.99 34.9 2.00 37.3 2.03 39.9 2.05 41.1 2.06
67 29.3 2.49 33.1 2.53 34.9 2.55 37.3 2.58 39.9 2.61 41.1 2.62
77 29.3 2.74 33.1 2.79 34.9 2.81 37.3 2.84 39.9 2.88 41.1 2.89
87 29.3 2.99 33.1 3.05 34.9 3.07 37.3 3.11 39.9 3.14 41.1 3.16
95 29.3 3.20 33.1 3.25 34.9 3.28 37.3 3.32 39.9 3.35 41.1 3.37
104 25.5 2.97 28.8 3.02 30.3 3.04 32.5 3.08 34.7 3.11 35.8 3.13
115 21.7 2.74 24.5 2.79 25.8 2.81 27.6 2.84 29.5 2.87 30.4 2.89
- 254 -
6-2. Cooling capacity 6. Capacity table
