 Unit: kW, °C
• TC: Total Capacity (kW), SHC: Sensible Heat Capacity (kW).
• The data is based on the following conditions:
Pipe length: 24.6 ft (7.5 m), Height difference: 0 ft (0 m) [Outdoor unit - Indoor unit]
MODEL: AGU9RLF
Outdoor temperature
Indoor temperature (°CDB / °CWB)
17.8 / 12.2 21.1 / 15.6 23.9 / 17.2 26.7 / 19.4 29.4 / 21.7 32.2 / 22.8
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 2.21 1.51 2.49 1.72 2.63 1.98 2.81 2.22 3.01 2.43 3.10 2.79
-5.0 2.21 1.51 2.49 1.72 2.63 1.98 2.81 2.22 3.01 2.43 3.10 2.79
0.0 2.21 1.51 2.49 1.72 2.63 1.98 2.81 2.22 3.01 2.43 3.10 2.79
5.0 2.21 1.51 2.49 1.72 2.63 1.98 2.81 2.22 3.01 2.43 3.10 2.79
10.0 2.21 1.51 2.49 1.72 2.63 1.98 2.81 2.22 3.01 2.43 3.10 2.79
15.0 2.21 1.51 2.49 1.72 2.63 1.98 2.81 2.22 3.01 2.43 3.10 2.79
20.0 2.21 1.51 2.49 1.72 2.63 1.98 2.81 2.22 3.01 2.43 3.10 2.79
25.0 2.21 1.51 2.49 1.72 2.63 1.98 2.81 2.22 3.01 2.43 3.10 2.79
30.0 2.21 1.51 2.49 1.72 2.63 1.98 2.81 2.22 3.01 2.43 3.10 2.79
35.0 2.21 1.51 2.49 1.72 2.63 1.98 2.81 2.22 3.01 2.43 3.10 2.79
40.0 2.09 1.35 2.36 1.54 2.49 1.77 2.66 1.99 2.85 2.18 2.93 2.49
46.1 1.97 1.20 2.22 1.37 2.35 1.58 2.51 1.77 2.68 1.94 2.77 2.22
MODEL: AGU12RLF
Outdoor temperature
Indoor temperature (°CDB / °CWB)
17.8 / 12.2 21.1 / 15.6 23.9 / 17.2 26.7 / 19.4 29.4 / 21.7 32.2 / 22.8
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 2.94 1.88 3.32 2.15 3.50 2.47 3.75 2.78 4.01 3.04 4.13 3.48
-5.0 2.94 1.88 3.32 2.15 3.50 2.47 3.75 2.78 4.01 3.04 4.13 3.48
0.0 2.94 1.88 3.32 2.15 3.50 2.47 3.75 2.78 4.01 3.04 4.13 3.48
5.0 2.94 1.88 3.32 2.15 3.50 2.47 3.75 2.78 4.01 3.04 4.13 3.48
10.0 2.94 1.88 3.32 2.15 3.50 2.47 3.75 2.78 4.01 3.04 4.13 3.48
15.0 2.94 1.88 3.32 2.15 3.50 2.47 3.75 2.78 4.01 3.04 4.13 3.48
20.0 2.94 1.88 3.32 2.15 3.50 2.47 3.75 2.78 4.01 3.04 4.13 3.48
25.0 2.94 1.88 3.32 2.15 3.50 2.47 3.75 2.78 4.01 3.04 4.13 3.48
30.0 2.94 1.88 3.32 2.15 3.50 2.47 3.75 2.78 4.01 3.04 4.13 3.48
35.0 2.94 1.88 3.32 2.15 3.50 2.47 3.75 2.78 4.01 3.04 4.13 3.48
40.0 2.78 1.69 3.14 1.92 3.32 2.21 3.55 2.49 3.79 2.72 3.91 3.11
46.1 2.62 1.50 2.97 1.71 3.13 1.97 3.35 2.21 3.58 2.42 3.69 2.77
MODEL: AGU15RLF
Outdoor temperature
Indoor temperature (°CDB / °CWB)
17.8 / 12.2 21.1 / 15.6 23.9 / 17.2 26.7 / 19.4 29.4 / 21.7 32.2 / 22.8
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 3.68 2.29 4.15 2.61 4.38 3.01 4.69 3.38 5.01 3.69 5.17 4.23
-5.0 3.68 2.29 4.15 2.61 4.38 3.01 4.69 3.38 5.01 3.69 5.17 4.23
0.0 3.68 2.29 4.15 2.61 4.38 3.01 4.69 3.38 5.01 3.69 5.17 4.23
5.0 3.68 2.29 4.15 2.61 4.38 3.01 4.69 3.38 5.01 3.69 5.17 4.23
10.0 3.68 2.29 4.15 2.61 4.38 3.01 4.69 3.38 5.01 3.69 5.17 4.23
15.0 3.68 2.29 4.15 2.61 4.38 3.01 4.69 3.38 5.01 3.69 5.17 4.23
20.0 3.68 2.29 4.15 2.61 4.38 3.01 4.69 3.38 5.01 3.69 5.17 4.23
25.0 3.68 2.29 4.15 2.61 4.38 3.01 4.69 3.38 5.01 3.69 5.17 4.23
30.0 3.68 2.29 4.15 2.61 4.38 3.01 4.69 3.38 5.01 3.69 5.17 4.23
35.0 3.68 2.29 4.15 2.61 4.38 3.01 4.69 3.38 5.01 3.69 5.17 4.23
40.0 3.48 2.05 3.93 2.34 4.14 2.69 4.44 3.02 4.74 3.31 4.89 3.79
46.1 3.28 1.82 3.71 2.08 3.91 2.39 4.18 2.69 4.47 2.94 4.61 3.37
- 273 -
6-2. Cooling capacity 6. Capacity table
