 Unit: kW, °C
• TC: Total Capacity (kW).
• The data is based on the following conditions:
Pipe length: 24.6 ft (7.5 m), Height difference: 0 ft (0 m) [Outdoor unit - Indoor unit]
MODEL: AGU9RLF
Outdoor temperature
Indoor temperature (°CDB)
15.6 18.3 21.1 23.9 25.6
(°CDB) (°CWB) TC TC TC TC TC
-15.0 -16.1 1.94 1.90 1.85 1.80 1.76
-10.0 -11.1 2.19 2.14 2.08 2.03 1.98
-5.0 -7.2 2.44 2.38 2.32 2.26 2.20
0.0 -2.2 2.84 2.77 2.70 2.64 2.57
5.0 2.8 3.24 3.16 3.09 3.01 2.93
8.3 6.1 3.32 3.24 3.17 3.09 3.01
10.0 8.3 3.32 3.24 3.17 3.09 3.01
15.0 10.0 3.32 3.24 3.17 3.09 3.01
20.0 15.0 3.17 3.10 3.02 2.95 2.87
23.9 18.3 3.02 2.95 2.88 2.81 2.74
MODEL: AGU12RLF
Outdoor temperature
Indoor temperature (°CDB)
15.6 18.3 21.1 23.9 25.6
(°CDB) (°CWB) TC TC TC TC TC
-15.0 -16.1 2.59 2.53 2.47 2.40 2.34
-10.0 -11.1 2.92 2.85 2.78 2.71 2.64
-5.0 -7.2 3.25 3.17 3.09 3.02 2.94
0.0 -2.2 3.79 3.69 3.60 3.51 3.42
5.0 2.8 4.32 4.22 4.12 4.01 3.91
8.3 6.1 4.43 4.33 4.22 4.11 4.01
10.0 8.3 4.43 4.33 4.22 4.11 4.01
15.0 10.0 4.43 4.33 4.22 4.11 4.01
20.0 15.0 4.23 4.13 4.03 3.93 3.83
23.9 18.3 4.03 3.94 3.84 3.74 3.65
MODEL: AGU15RLF
Outdoor temperature
Indoor temperature (°CDB)
15.6 18.3 21.1 23.9 25.6
(°CDB) (°CWB) TC TC TC TC TC
-15.0 -16.1 3.24 3.16 3.08 3.00 2.93
-10.0 -11.1 3.65 3.56 3.47 3.39 3.30
-5.0 -7.2 4.06 3.96 3.87 3.77 3.67
0.0 -2.2 4.73 4.62 4.51 4.39 4.28
5.0 2.8 5.40 5.27 5.14 5.02 4.89
8.3 6.1 5.54 5.41 5.28 5.14 5.01
10.0 8.3 5.54 5.41 5.28 5.14 5.01
15.0 10.0 5.54 5.41 5.28 5.14 5.01
20.0 15.0 5.29 5.16 5.03 4.91 4.78
23.9 18.3 5.04 4.92 4.80 4.68 4.56
- 293 -
6-3. Heating capacity 6. Capacity table
OUTDOOR UNIT AOU45RLXFZ OUTDOOR UNIT AOU45RLXFZ
