7-3. Current release control
The compressor frequency is controlled so that the outdoor unit input current does not exceeds cur-
rent limit value set according to the outdoor temperature.
The compressor frequency returns according to the operation mode, when the current becomes low-
er than the release value.
¢ Model: AOUH09LUAS1
Operation mode Outdoor temp. (Ta) Trigger condition Release condition
Cooling
122.0°F (50°C) ≤ Ta 4.0 A 3.5 A
114.8°F (46°C) ≤ Ta < 122.0°F (50°C) 4.0 A 3.5 A
104.0°F (40°C) ≤ Ta < 114.8°F (46°C) 5.0 A 4.5 A
53.6°F (12°C) ≤ Ta < 104.0°F (40°C) 6.0 A 5.5 A
35.6°F (2°C) ≤ Ta < 53.6°F (12°C) 6.0 A 5.5 A
Ta < 35.6°F (2°C) 6.0 A 5.5 A
Heating
62.6°F (17°C) ≤ Ta 5.5 A 5.0 A
53.6°F (12°C) ≤ Ta < 62.6°F (17°C) 7.0 A 6.5 A
41.0°F (5°C) ≤ Ta < 53.6°F (12°C) 7.5 A 7.0 A
Ta < 41.0°F (5°C) 8.5 A 8.0 A
¢ Model: AOUH12LUAS1
Operation mode Outdoor temp. (Ta) Trigger condition Release condition
Cooling
122.0°F (50°C) ≤ Ta 4.5 A 4.0 A
114.8°F (46°C) ≤ Ta < 122.0°F (50°C) 4.5 A 4.0 A
104.0°F (40°C) ≤ Ta < 114.8°F (46°C) 6.0 A 5.5 A
53.6°F (12°C) ≤ Ta < 104.0°F (40°C) 8.5 A 8.0 A
35.6°F (2°C) ≤ Ta < 53.6°F (12°C) 8.5 A 8.0 A
Ta < 35.6°F (2°C) 8.5 A 8.0 A
Heating
62.6°F (17°C) ≤ Ta 7.0 A 6.5 A
53.6°F (12°C) ≤ Ta < 62.6°F (17°C) 9.0 A 8.5 A
41.0°F (5°C) ≤ Ta < 53.6°F (12°C) 10.0 A 9.5 A
Ta < 41.0°F (5°C) 10.0 A 9.5 A
¢ Model: AOUH18LUAS1
Operation mode Outdoor temp. (Ta) Trigger condition Release condition
Cooling
122.0°F (50°C) ≤ Ta 4.5 A 4.0 A
114.8°F (46°C) ≤ Ta < 122.0°F (50°C) 4.5 A 4.0 A
104.0°F (40°C) ≤ Ta < 114.8°F (46°C) 6.0 A 5.5 A
53.6°F (12°C) ≤ Ta < 104.0°F (40°C) 10.0 A 9.5 A
35.6°F (2°C) ≤ Ta < 53.6°F (12°C) 10.0 A 9.5 A
Ta < 35.6°F (2°C) 10.0 A 9.5 A
Heating
62.6°F (17°C) ≤ Ta 7.0 A 6.5 A
53.6°F (12°C) ≤ Ta < 62.6°F (17°C) 9.0 A 8.5 A
41.0°F (5°C) ≤ Ta < 53.6°F (12°C) 12.5 A 12.0 A
Ta < 41.0°F (5°C) 12.5 A 12.0 A
7-3. Current release control - (04-30) - 7. Various protections
