Page #23 background image
Item no. Part no. Part name Service part
50 9379570015 Sirocco fan assy
51 9379572019 Casing B
52 9378593039 Float switch sub assy
53 9379913003 Drain hose assy
54 9378450141 Hose sub assy
55 9379914062 Drain pump sub assy
56
9711875068 Main PCB (09 model)
9711875075 Main PCB (12 model)
57 9710019005 2-way remote PCB
58 9900896027 Terminal 5P (Remote)
59 9900568009 Terminal 3P
60 9710661020 Power supply PCB
61 9900653019 Thermistor (Room)
62 9900349035 Thermistor (Pipe)
63 9379908030 Top panel sub assy
64 9379571012 Casing U
65 9379644006 Vibration-proof rubber assy
66 9379047159 Motor sub assy
9710177057
→ire with connector
(CN46 on Main PCB—Terminal 5P [External input])
9710171055
→ire with connector
(CN260 on Main PCB—CN262 on Power supply PCB)
9710206047
→ire with connector
(CN261 on Main PCB—CN263 on Power supply PCB)
9710343094
→ire with connector
(CN300 on Main PCB—Terminal 5P [Remote])
9710703010
→ire with connector
(CN205 on Power supply PCB—Terminal 3P)
2-1. Models: ADUH09LUAS1 and ADUH12LUAS1 - (02-5) - 2. Indoor unit parts list
TECHNICAL DATA
AND PARTS LIST
TECHNICAL DATA
AND PARTS LIST
